MOD. | Screen Area | Maximum FlowRate | Connections | Dimentions | Weight | |||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
in\out | Drain | A | B | C | D | E | F | X | ||||||
(cm2) | (m2) | (m3/h) | Liter | (in-mm) | (in-mm) | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | (kg) | |
Arabo40 | 2.200 | 341 | 40 | 666 | 2η | 2/1η | 366 | 206 | 1070 | 790 | 640 | 420 | 700 | 27 |
Arabo60 | 2.200 | 341 | 60 | 999 | 80 | 2/1η | 406 | 206 | 1070 | 790 | 640 | 435 | 700 | 32 |
Arabo75 | 3.300 | 512 | 75 | 1249 | 80 | 2/1η | 470 | 273 | 1190 | 860 | 610 | 430 | 700 | 44 |
Arabo90 | 3.300 | 512 | 90 | 1498 | 100 | 2/1η | 470 | 273 | 1190 | 860 | 610 | 430 | 700 | 45 |
Arabo110 | 5.400 | 837 | 110 | 1831 | 100 | 2/1η | 470 | 273 | 1470 | 1140 | 890 | 430 | 1000 | 57 |
Arabo250 | 5.400 | 837 | 250 | 4163 | 150 | 2/1η | 473 | 273 | 1480 | 1150 | 900 | 430 | 1000 | 59 |
Arabo380 | 5.400 | 873 | 380 | 6328 | 150 | 2/1η | 473 | 273 | 1580 | 1195 | 895 | 430 | 1000 | 63 |
MOD. | Screen Area | Maximum FlowRate | Connections | Dimentions | Weight | |||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
in\out | Drain | A | B | C | D | E | F | X | ||||||
(cm2) | (m2) | (m3/h) | Liter | (in-mm) | (in-mm) | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | (kg) | |
Arabo40 | 2.200 | 341 | 40 | 666 | 2η | 2/1η | 366 | 206 | 1070 | 790 | 640 | 420 | 700 | 27 |
Arabo60 | 2.200 | 341 | 60 | 999 | 80 | 2/1η | 406 | 206 | 1070 | 790 | 640 | 435 | 700 | 32 |
Arabo75 | 3.300 | 512 | 75 | 1249 | 80 | 2/1η | 470 | 273 | 1190 | 860 | 610 | 430 | 700 | 44 |
Arabo90 | 3.300 | 512 | 90 | 1498 | 100 | 2/1η | 470 | 273 | 1190 | 860 | 610 | 430 | 700 | 45 |
Arabo110 | 5.400 | 837 | 110 | 1831 | 100 | 2/1η | 470 | 273 | 1470 | 1140 | 890 | 430 | 1000 | 57 |
Arabo250 | 5.400 | 837 | 250 | 4163 | 150 | 2/1η | 473 | 273 | 1480 | 1150 | 900 | 430 | 1000 | 59 |
Arabo380 | 5.400 | 873 | 380 | 6328 | 150 | 2/1η | 473 | 273 | 1580 | 1195 | 895 | 430 | 1000 | 63 |
