Leaf Filter

Filter Area {m2}	Filter Leaves	Filter Volume {dm2}	Floor Space {mmxmm}
2	5	210	1420×1150
5	7	430	1540×1210
8	9	760	1710×1890
12	7	1050	1945×1830
14	9
19	8	1690	2360×1600
22	10
24	12
27	10	2520	2720×1790
31	12
34	14
37	12	2855	2720×1790
40	14
45	15	3540	3100×2080
48	17
54	15	3990	3100×2080
57	17
61	14	5440	3100×2080
67	16
72	18
80	16	7115	4300×2710
86	18
92	20
95	21
99	18	9475	4500×2350
107	20
113	22
118	24

Filter Area {m2}	Filter Leaves	Filter Volume {dm2}	Floor Space {mmxmm}
2	5	210	1420×1150
5	7	430	1540×1210
8	9	760	1710×1890
12	7	1050	1945×1830
14	9
19	8	1690	2360×1600
22	10
24	12
27	10	2520	2720×1790
31	12
34	14
37	12	2855	2720×1790
40	14
45	15	3540	3100×2080
48	17
54	15	3990	3100×2080
57	17
61	14	5440	3100×2080
67	16
72	18
80	16	7115	4300×2710
86	18
92	20
95	21
99	18	9475	4500×2350
107	20
113	22
118	24

DESCRIPTION

The leaf is considered as the heart of the filter and its most critical part. Each leaf consists of many layers of wire mesh fastened by rivets held in a tubular frame. The ribs on both sides of each leaf serve as the stream of the fluid filtered through the neck. It is covered with coarse screen mesh that supports the Dutch weave which retains the cake. The space between each leaf varies between 3-10 cm depending on the size of the cake formed on the leaf. Each leaf can be removed for changing or repairing purposes.

Pressure Leaf Filter

Today’s Arabo state of the art Pressure Leaf Filter is the fruit of continuous improvements to one of the most utilized and sold filters in the filtration field. Our filter is widely used in the food industry where it’s employed to remove impurity and sludge content from palm oil and other types of edible oils. The filter elements comprise a stainless steel screen with a top screen of 24 X 110 Dutch Weave.
